John Guest - LLDPE Polypropylene Tubing
Technical Details
| Material | LLDPE (Linear Low-Density Polyethylene) |
| Certifications | NSF 51 & 61, FDA approved materials |
| Maximum Pressure (70°F) | 230 psi |
| Maximum Pressure (150°F) | 120 psi |
| Temperature Range | Low-temperature rated, up to 150°F |
| Characteristics | Flexible, odorless, tasteless, non-toxic |
| Chemical Resistance | Substantial resistance to common chemicals |
| Packaging | Plastic spool, rack-mountable |
Working with John Guest Tubing
- Cut tubing to length using a sharp blade or tubing cutter, ensuring a clean, square cut with no burrs or deformation
- Insert tubing fully into John Guest push-to-connect fittings or compatible OD connectors until seated against the internal stop
- Verify connection by gently tugging on the tubing to confirm engagement with the collet mechanism
- Pressurize system gradually and inspect all connections for leaks before placing into service
- Store unused tubing on the spool away from direct sunlight and extreme temperatures to maintain flexibility
Applications & Systems
This LLDPE tubing works with most OD tubing connectors and is specifically designed for use with John Guest push-to-connect fittings and valves. Common applications include reverse osmosis systems, water purification equipment, ice makers, misting systems, car wash installations, home and office coffee machines, beverage dispensing equipment, and pneumatic control lines. The tubing's chemical resistance and temperature tolerance make it suitable for both potable water and light chemical transfer applications.
Technical Details
| Material | LLDPE (Linear Low-Density Polyethylene) |
| Certifications | NSF 51 & 61, FDA approved materials |
| Maximum Pressure (70°F) | 230 psi |
| Maximum Pressure (150°F) | 120 psi |
| Temperature Range | Low-temperature rated, up to 150°F |
| Characteristics | Flexible, odorless, tasteless, non-toxic |
| Chemical Resistance | Substantial resistance to common chemicals |
| Packaging | Plastic spool, rack-mountable |
Working with John Guest Tubing
- Cut tubing to length using a sharp blade or tubing cutter, ensuring a clean, square cut with no burrs or deformation
- Insert tubing fully into John Guest push-to-connect fittings or compatible OD connectors until seated against the internal stop
- Verify connection by gently tugging on the tubing to confirm engagement with the collet mechanism
- Pressurize system gradually and inspect all connections for leaks before placing into service
- Store unused tubing on the spool away from direct sunlight and extreme temperatures to maintain flexibility
Applications & Systems
This LLDPE tubing works with most OD tubing connectors and is specifically designed for use with John Guest push-to-connect fittings and valves. Common applications include reverse osmosis systems, water purification equipment, ice makers, misting systems, car wash installations, home and office coffee machines, beverage dispensing equipment, and pneumatic control lines. The tubing's chemical resistance and temperature tolerance make it suitable for both potable water and light chemical transfer applications.
Original: $0.25
-64%$0.25
$0.09Description
Technical Details
| Material | LLDPE (Linear Low-Density Polyethylene) |
| Certifications | NSF 51 & 61, FDA approved materials |
| Maximum Pressure (70°F) | 230 psi |
| Maximum Pressure (150°F) | 120 psi |
| Temperature Range | Low-temperature rated, up to 150°F |
| Characteristics | Flexible, odorless, tasteless, non-toxic |
| Chemical Resistance | Substantial resistance to common chemicals |
| Packaging | Plastic spool, rack-mountable |
Working with John Guest Tubing
- Cut tubing to length using a sharp blade or tubing cutter, ensuring a clean, square cut with no burrs or deformation
- Insert tubing fully into John Guest push-to-connect fittings or compatible OD connectors until seated against the internal stop
- Verify connection by gently tugging on the tubing to confirm engagement with the collet mechanism
- Pressurize system gradually and inspect all connections for leaks before placing into service
- Store unused tubing on the spool away from direct sunlight and extreme temperatures to maintain flexibility
Applications & Systems
This LLDPE tubing works with most OD tubing connectors and is specifically designed for use with John Guest push-to-connect fittings and valves. Common applications include reverse osmosis systems, water purification equipment, ice makers, misting systems, car wash installations, home and office coffee machines, beverage dispensing equipment, and pneumatic control lines. The tubing's chemical resistance and temperature tolerance make it suitable for both potable water and light chemical transfer applications.
