Omnipure - K2350 - 6" x 2" GAC with 0.25 lb of KDF-55 Inline Filter

Product image 1
1 / 3

Omnipure - K2350 - 6" x 2" GAC with 0.25 lb of KDF-55 Inline Filter

Omnipure K-Series

K2350 Inline Filter with KDF-55

6" x 2" GAC and KDF media for chlorine, heavy metal, and scale reduction in compact inline applications
0.25 lb KDF-55 1/4" & 3/8" NPT 0.5 GPM Flow Rate 125 PSI Max

The Omnipure K2350 combines granulated activated carbon with a quarter pound of KDF-55 media in a 6-inch inline housing. The dual-threaded design with 1/4" and 3/8" female NPT fittings provides installation flexibility across a range of under-counter filtration systems, refrigerators, and ice makers.

HOW IT WORKS

Two-Stage Filtration in One Inline Cartridge

1
KDF-55

Redox Media Reduction

KDF-55 copper-zinc alloy removes chlorine, soluble heavy metals like lead and mercury, and controls bacterial growth through redox reactions before water reaches the carbon bed.

2
GAC

Activated Carbon Polishing

Granulated activated carbon adsorbs residual chlorine, taste and odor compounds, and organic contaminants for final water quality improvement before the outlet fitting.

SPECIFICATIONS

K2350 Technical Details

Model Number K2350
Dimensions 6" L x 2" W
Inlet/Outlet Fittings 1/4" FPT and 3/8" FPT (both sides)
Flow Rate 0.5 GPM
Maximum Pressure 125 PSI
Maximum Temperature 100°F
Filtration Media GAC with 0.25 lb KDF-55
Primary Contaminants Chlorine, heavy metals, taste, odor, scale, bacteria, algae
COMPATIBILITY

Installation Applications

The K2350 works with reverse osmosis systems, under-counter drinking water filters, refrigerator water lines, and ice maker supply lines that require inline filtration with dual NPT thread options. Both 1/4-inch and 3/8-inch female threads are present on each end, allowing direct connection to standard water tubing or male NPT fittings without adapters. Note that NPT threads measure larger than their nominal size when measured with a ruler: 1/4" NPT measures approximately 0.540 inches in actual diameter, and 3/8" NPT measures approximately 0.675 inches.

Omnipure K-Series

K2350 Inline Filter with KDF-55

6" x 2" GAC and KDF media for chlorine, heavy metal, and scale reduction in compact inline applications
0.25 lb KDF-55 1/4" & 3/8" NPT 0.5 GPM Flow Rate 125 PSI Max

The Omnipure K2350 combines granulated activated carbon with a quarter pound of KDF-55 media in a 6-inch inline housing. The dual-threaded design with 1/4" and 3/8" female NPT fittings provides installation flexibility across a range of under-counter filtration systems, refrigerators, and ice makers.

HOW IT WORKS

Two-Stage Filtration in One Inline Cartridge

1
KDF-55

Redox Media Reduction

KDF-55 copper-zinc alloy removes chlorine, soluble heavy metals like lead and mercury, and controls bacterial growth through redox reactions before water reaches the carbon bed.

2
GAC

Activated Carbon Polishing

Granulated activated carbon adsorbs residual chlorine, taste and odor compounds, and organic contaminants for final water quality improvement before the outlet fitting.

SPECIFICATIONS

K2350 Technical Details

Model Number K2350
Dimensions 6" L x 2" W
Inlet/Outlet Fittings 1/4" FPT and 3/8" FPT (both sides)
Flow Rate 0.5 GPM
Maximum Pressure 125 PSI
Maximum Temperature 100°F
Filtration Media GAC with 0.25 lb KDF-55
Primary Contaminants Chlorine, heavy metals, taste, odor, scale, bacteria, algae
COMPATIBILITY

Installation Applications

The K2350 works with reverse osmosis systems, under-counter drinking water filters, refrigerator water lines, and ice maker supply lines that require inline filtration with dual NPT thread options. Both 1/4-inch and 3/8-inch female threads are present on each end, allowing direct connection to standard water tubing or male NPT fittings without adapters. Note that NPT threads measure larger than their nominal size when measured with a ruler: 1/4" NPT measures approximately 0.540 inches in actual diameter, and 3/8" NPT measures approximately 0.675 inches.

Select Connection
Select Choose
From $6.01

Original: $17.16

-65%
Omnipure - K2350 - 6" x 2" GAC with 0.25 lb of KDF-55 Inline Filter—

$17.16

$6.01

Description

Omnipure K-Series

K2350 Inline Filter with KDF-55

6" x 2" GAC and KDF media for chlorine, heavy metal, and scale reduction in compact inline applications
0.25 lb KDF-55 1/4" & 3/8" NPT 0.5 GPM Flow Rate 125 PSI Max

The Omnipure K2350 combines granulated activated carbon with a quarter pound of KDF-55 media in a 6-inch inline housing. The dual-threaded design with 1/4" and 3/8" female NPT fittings provides installation flexibility across a range of under-counter filtration systems, refrigerators, and ice makers.

HOW IT WORKS

Two-Stage Filtration in One Inline Cartridge

1
KDF-55

Redox Media Reduction

KDF-55 copper-zinc alloy removes chlorine, soluble heavy metals like lead and mercury, and controls bacterial growth through redox reactions before water reaches the carbon bed.

2
GAC

Activated Carbon Polishing

Granulated activated carbon adsorbs residual chlorine, taste and odor compounds, and organic contaminants for final water quality improvement before the outlet fitting.

SPECIFICATIONS

K2350 Technical Details

Model Number K2350
Dimensions 6" L x 2" W
Inlet/Outlet Fittings 1/4" FPT and 3/8" FPT (both sides)
Flow Rate 0.5 GPM
Maximum Pressure 125 PSI
Maximum Temperature 100°F
Filtration Media GAC with 0.25 lb KDF-55
Primary Contaminants Chlorine, heavy metals, taste, odor, scale, bacteria, algae
COMPATIBILITY

Installation Applications

The K2350 works with reverse osmosis systems, under-counter drinking water filters, refrigerator water lines, and ice maker supply lines that require inline filtration with dual NPT thread options. Both 1/4-inch and 3/8-inch female threads are present on each end, allowing direct connection to standard water tubing or male NPT fittings without adapters. Note that NPT threads measure larger than their nominal size when measured with a ruler: 1/4" NPT measures approximately 0.540 inches in actual diameter, and 3/8" NPT measures approximately 0.675 inches.
