Pentek - Slim Line 10" Filter Housing - Blue Cap / Clear Sump
10" Filter Housing with Blue Cap / Clear Sump
Reinforced polypropylene housing for under-sink, countertop, and light commercial filtration. Clear sump lets you see when it's time to change the filter.
Compact Design for Residential and Light Commercial Use
Clear Sump Design
See your filter cartridge and sediment buildup at a glance. Know exactly when maintenance is needed without guessing.
Leak-Proof O-Ring Seal
Top-seated Buna-N O-ring creates a reliable seal. Rated for 125 PSI at temperatures up to 125°F.
Space-Saving Profile
Slim 4-3/8" diameter fits under sinks and in tight spaces. Full 10" cartridge capacity in a compact footprint.
Multiple Port Options
Reinforced polypropylene cap with 1/4", 3/8", or 1/2" NPT connections. Four molded mounting bosses for secure installation.
Chemical Resistant
Polypropylene cap and SAN sump handle a wide range of water chemistries. Stainless steel button assembly resists corrosion.
Technical Details
| Housing Material | Styrene Acrylonitrile (SAN), Clear Sump |
| Cap Material | Reinforced Polypropylene, Blue |
| O-Ring Material | Buna-N, Top-Seated |
| Button Assembly | 300-Series Stainless Steel, Polypropylene, EPDM |
| Maximum Pressure | 125 PSI (8.62 bar) |
| Maximum Temperature | 125°F (51.7°C) |
| Dimensions | 11-3/4" H x 4-3/8" Dia |
| Flow Rate | 3 GPM @ 2 PSI pressure drop |
| Port Sizes | 1/4", 3/8", or 1/2" NPT |
Accepts Standard 10-Inch Filter Cartridges
This Pentek Slim Line housing accepts any standard 10" x 2.5" diameter filter cartridge, including sediment filters, carbon block filters, pleated filters, and specialty cartridges. Common applications include pre-RO filtration, post-RO polishing, under-sink drinking water systems, ice makers, coffee equipment, humidifiers, and light commercial filtration.
Filter Cartridge Replacement
Sediment Filters
Replace 5 or 1 micron sediment cartridges every 3-6 months depending on water quality and flow volume. Clear sump shows sediment buildup.
Carbon Block Filters
Replace carbon block cartridges every 6-12 months for chlorine, taste, and odor reduction. Performance degrades over time even if flow remains steady.
O-Ring Inspection
Inspect the Buna-N O-ring each time you change the filter. Replace if cracked, flattened, or hardened. Lubricate lightly with silicone grease during reassembly.
Residential Proven
Widely used in under-sink and countertop drinking water systems
FDA Grade Materials
Safe for potable water contact and food service applications
Easy Maintenance
Clear sump and simple twist-off design make filter changes straightforward
Built to Last
Reinforced polypropylene and stainless steel construction for long service life
