Pentek - Slim Line 10" Filter Housing - White Cap / White Sump
10" White Cap / White Sump Filter Housing
The Pentek Slim Line 10" housing combines the durability of reinforced polypropylene construction with a compact footprint that fits where standard housings won't. With four molded mounting bosses, leak-proof Buna-N O-ring sealing, and a choice of 1/4", 3/8", or 1/2" NPT connections, this housing delivers reliable filtration in a package that's 40% slimmer than traditional designs.
Built for Residential and Light Commercial Use
| Housing Material | Reinforced Polypropylene (Opaque) |
| Cap Material | Reinforced Polypropylene |
| O-Ring Material | Buna-N (Top-Seated) |
| Button Assembly | 300-Series Stainless Steel, Polypropylene, EPDM |
| Maximum Pressure | 125 PSI (8.62 bar) |
| Maximum Temperature | 125°F (51.7°C) |
| Dimensions | 11-3/4" x 4-3/8" |
| Flow Rate Performance | 2 PSI pressure drop at 3 GPM |
| Port Options | 1/4", 3/8", or 1/2" NPT |
| Mounting | Four molded bosses in cap |
| FDA Compliance | FDA-grade materials |
Applications and Filter Cartridges
This Pentek Slim Line housing accepts all standard 10-inch filter cartridges with 2.5-inch outer diameters. Common applications include under-sink and countertop residential filtration, pre-RO and post-RO filtration stages, recreational vehicle water systems, food service equipment, humidifying systems, and light commercial or industrial filtration. The opaque white sump construction makes it ideal for carbon filters where light exposure could promote bacterial growth, while the reinforced polypropylene material ensures broad chemical compatibility across chlorinated, acidic, and alkaline water sources. Pair with sediment, carbon block, pleated polyester, or specialty cartridges depending on your water quality needs.
10" White Cap / White Sump Filter Housing
The Pentek Slim Line 10" housing combines the durability of reinforced polypropylene construction with a compact footprint that fits where standard housings won't. With four molded mounting bosses, leak-proof Buna-N O-ring sealing, and a choice of 1/4", 3/8", or 1/2" NPT connections, this housing delivers reliable filtration in a package that's 40% slimmer than traditional designs.
Built for Residential and Light Commercial Use
| Housing Material | Reinforced Polypropylene (Opaque) |
| Cap Material | Reinforced Polypropylene |
| O-Ring Material | Buna-N (Top-Seated) |
| Button Assembly | 300-Series Stainless Steel, Polypropylene, EPDM |
| Maximum Pressure | 125 PSI (8.62 bar) |
| Maximum Temperature | 125°F (51.7°C) |
| Dimensions | 11-3/4" x 4-3/8" |
| Flow Rate Performance | 2 PSI pressure drop at 3 GPM |
| Port Options | 1/4", 3/8", or 1/2" NPT |
| Mounting | Four molded bosses in cap |
| FDA Compliance | FDA-grade materials |
Applications and Filter Cartridges
This Pentek Slim Line housing accepts all standard 10-inch filter cartridges with 2.5-inch outer diameters. Common applications include under-sink and countertop residential filtration, pre-RO and post-RO filtration stages, recreational vehicle water systems, food service equipment, humidifying systems, and light commercial or industrial filtration. The opaque white sump construction makes it ideal for carbon filters where light exposure could promote bacterial growth, while the reinforced polypropylene material ensures broad chemical compatibility across chlorinated, acidic, and alkaline water sources. Pair with sediment, carbon block, pleated polyester, or specialty cartridges depending on your water quality needs.
