SharkBite-Reducing Male Connector
SharkBite Reducing Male Connector
The SharkBite Reducing Male Connector delivers a permanent connection between dissimilar pipe materials without soldering, gluing, or specialized tools. One end features SharkBite's push-to-connect system, while the other terminates in a standard male NPT thread for direct connection to threaded fixtures and valves.
Technical Details
| Manufacturer | SharkBite |
| Connection Type | Push-to-Connect to Male NPT |
| Maximum Pressure | 200 PSI |
| Maximum Temperature | 200°F |
| Installation Method | Tool-Free Push-Fit |
| Application | Potable Water, Radiant Heating |
| Installation Location | Above/Below Ground, Behind Wall |
Approved Pipe Materials
This SharkBite reducing male connector is compatible with copper, PEX, CPVC, PE-RT, and SDR9 HDPE pipe. The push-fit end accepts pipe directly without preparation beyond a clean, square cut. The male NPT threaded end connects to any standard female NPT fitting, valve, or fixture. Suitable for potable water systems and radiant heating applications, including installations that are underground or concealed behind walls where access panels are not provided.
SharkBite Reducing Male Connector
The SharkBite Reducing Male Connector delivers a permanent connection between dissimilar pipe materials without soldering, gluing, or specialized tools. One end features SharkBite's push-to-connect system, while the other terminates in a standard male NPT thread for direct connection to threaded fixtures and valves.
Technical Details
| Manufacturer | SharkBite |
| Connection Type | Push-to-Connect to Male NPT |
| Maximum Pressure | 200 PSI |
| Maximum Temperature | 200°F |
| Installation Method | Tool-Free Push-Fit |
| Application | Potable Water, Radiant Heating |
| Installation Location | Above/Below Ground, Behind Wall |
Approved Pipe Materials
This SharkBite reducing male connector is compatible with copper, PEX, CPVC, PE-RT, and SDR9 HDPE pipe. The push-fit end accepts pipe directly without preparation beyond a clean, square cut. The male NPT threaded end connects to any standard female NPT fitting, valve, or fixture. Suitable for potable water systems and radiant heating applications, including installations that are underground or concealed behind walls where access panels are not provided.
Original: $12.82
-65%$12.82
$4.49Description
SharkBite Reducing Male Connector
The SharkBite Reducing Male Connector delivers a permanent connection between dissimilar pipe materials without soldering, gluing, or specialized tools. One end features SharkBite's push-to-connect system, while the other terminates in a standard male NPT thread for direct connection to threaded fixtures and valves.
Technical Details
| Manufacturer | SharkBite |
| Connection Type | Push-to-Connect to Male NPT |
| Maximum Pressure | 200 PSI |
| Maximum Temperature | 200°F |
| Installation Method | Tool-Free Push-Fit |
| Application | Potable Water, Radiant Heating |
| Installation Location | Above/Below Ground, Behind Wall |
Approved Pipe Materials
This SharkBite reducing male connector is compatible with copper, PEX, CPVC, PE-RT, and SDR9 HDPE pipe. The push-fit end accepts pipe directly without preparation beyond a clean, square cut. The male NPT threaded end connects to any standard female NPT fitting, valve, or fixture. Suitable for potable water systems and radiant heating applications, including installations that are underground or concealed behind walls where access panels are not provided.
